Bilstein 25-302240 B8 8100 (ZoneControl R DSA) - Suspension Shock Absorber
Product details
- Part Name Shock Absorber
- Position Front Left
- Brand Bilstein
- Country of Manufacture United States
- Part Number 25-302240
- UPC 651860949116
Estimate Delivery Date
Fitment is guaranteed:
If your vehicle is listed on the fitment table below, the product will fit your car - we guarantee it. All you need to do is to ensure that the vehicle's Year, Make, Model, Trim, and any other notes specified inside the fitment table are respected.
Included warranty:
This product has 2-year limited warranty.
- Warranty starts from the date of delivery.
- Proof of purchase required for all claims.
- Covers manufacturing defects only.
- Does not cover normal wear & tear.
- Does not cover cosmetic damage or rust damage.
To initiate a claim, simply send an email to support@partspioneer.ca. For more information, read our Warranty Policy.
Choose Bilstein because:
The B8 8100 (ZoneControl R DSA) reservoir shock absorber is an adjustable large bore 60mm (2.65" OD) direct fit solution for lifted trucks and SUVs. Click adjuster knobs allow easy and precise Dual Speed Adjustment of both low and high speed compression to tailor your ride to any surface. ZoneControl R is a revolutionary double piston technology delivering position sensitive rebound damping which eliminates harsh suspension top-out events and the need for an external limit strap. Each B8 8100 (DSA) offers a unique remote or piggyback reservoir solution for an easy hassle free installation. These shock absorbers feature a monotube design for consistent fade free performance and utilize velocity sensitive digressive valve settings which are tuned for each specific application. The large 60mm piston design offers more comfort and control in all driving conditions. The Bilstein B8 8100 (ZoneControl R DSA) offers unmatched levels of adjustable ride comfort and control.
Characteristics include:
- Adjustable Damping:Double Adjustable Compression with Click Adjuster Knobs
- Body Design:Smooth Body (Non-Coilover)
- Boot Included:No
- Collapsed Length (IN):14.65
- Collapsed Length (MM):372.2
- Extended Length (IN):22.99
- Extended Length (MM):584.0
- Finish:EVO Grey
- Internal Design:Monotube
- Lower Mount Type:Eye 14.1mm
- PartType:Shocks / Struts
- Piston Diameter:60mm
- Prop 65 (Y/N):Y
- Prop 65 - Short Label:WARNING: Cancer &
- Reproductive Harm - www.P65Warnings.ca.gov
- Reservoir:Yes
- Segment:Light Truck
- Series:B8 8100 (ZoneControl R DSA)
- Shaft Diameter:18mm
- Spring Seat Included:No
- Title:Bilstein Shock Absorbers
- Upper Mount Type:Stem
Some of the interchangeable part numbers are:
Customer Video Reviews
Watch genuine customer videos showing their upgrades and honest results of similar products
Fitment Table
This product is compatible with these vehicles:
| Year | Make | Model | Notes | Position |
|---|---|---|---|---|
| 2025 | Ram | 2500 |
|
Front Left |
| 2025 | Ram | 2500 |
|
Front Left |
| 2025 | Ram | 2500 |
|
Front Left |
| 2025 | Ram | 2500 |
|
Front Left |
| 2025 | Ram | 2500 |
|
Front Left |
| 2025 | Ram | 2500 |
|
Front Left |
| 2025 | Ram | 2500 |
|
Front Left |
| 2024 | Ram | 2500 |
|
Front Left |
| 2024 | Ram | 2500 |
|
Front Left |
| 2024 | Ram | 2500 |
|
Front Left |
| 2024 | Ram | 2500 |
|
Front Left |
| 2024 | Ram | 2500 |
|
Front Left |
| 2024 | Ram | 2500 |
|
Front Left |
| 2024 | Ram | 2500 |
|
Front Left |
| 2023 | Ram | 2500 |
|
Front Left |
| 2023 | Ram | 2500 |
|
Front Left |
| 2023 | Ram | 2500 |
|
Front Left |
| 2023 | Ram | 2500 |
|
Front Left |
| 2023 | Ram | 2500 |
|
Front Left |
| 2023 | Ram | 2500 |
|
Front Left |
| 2023 | Ram | 2500 |
|
Front Left |
| 2022 | Ram | 2500 |
|
Front Left |
| 2022 | Ram | 2500 |
|
Front Left |
| 2022 | Ram | 2500 |
|
Front Left |
| 2022 | Ram | 2500 |
|
Front Left |
| 2022 | Ram | 2500 |
|
Front Left |
| 2022 | Ram | 2500 |
|
Front Left |
| 2021 | Ram | 2500 |
|
Front Left |
| 2021 | Ram | 2500 |
|
Front Left |
| 2021 | Ram | 2500 |
|
Front Left |
| 2021 | Ram | 2500 |
|
Front Left |
| 2021 | Ram | 2500 |
|
Front Left |
| 2021 | Ram | 2500 |
|
Front Left |
| 2021 | Ram | 2500 |
|
Front Left |
| 2020 | Ram | 2500 |
|
Front Left |
| 2020 | Ram | 2500 |
|
Front Left |
| 2020 | Ram | 2500 |
|
Front Left |
| 2020 | Ram | 2500 |
|
Front Left |
| 2020 | Ram | 2500 |
|
Front Left |
| 2020 | Ram | 2500 |
|
Front Left |
| 2019 | Ram | 2500 |
|
Front Left |
| 2019 | Ram | 2500 |
|
Front Left |
| 2019 | Ram | 2500 |
|
Front Left |
| 2019 | Ram | 2500 |
|
Front Left |
| 2019 | Ram | 2500 |
|
Front Left |
| 2019 | Ram | 2500 |
|
Front Left |
