Bilstein 26-253275 MDS - Suspension Shock Absorber

Name: Bilstein 26-253275 MDS - Suspension Shock Absorber
Brand: Bilstein
SKU: BLS-26-253275
Availability: OutOfStock
Rating: 4.9 (487 reviews)

SKU: BLS-26-253275

VIN (optional)

If provided, we'll verify fitment before your order ships and contact you if the selected part is incompatible. Enter your VIN, then add the product to your cart.

Product details

Part Name Shock Absorber
Brand Bilstein
Country of Manufacture Germany
Part Number 26-253275
UPC 651860830209

Estimate Delivery Date

State

Have Questions?

Ask our experts via Live Chat at the bottom right corner of this page.

Fitment is guaranteed:

If your vehicle is listed on the fitment table below, the product will fit your car - we guarantee it. All you need to do is to ensure that the vehicle's Year, Make, Model, Trim, and any other notes specified inside the fitment table are respected.

Included warranty:

This product has 2-year limited warranty.

Warranty starts from the date of delivery.
Proof of purchase required for all claims.
Covers manufacturing defects only.
Does not cover normal wear & tear.
Does not cover cosmetic damage or rust damage.

To initiate a claim, simply send an email to support@partspioneer.ca. For more information, read our Warranty Policy.

Choose Bilstein because:

Bilstein MDS (Modular Damping System) dampers are a premium motorsports product designed for professional road racing. The 2-way independent compression and rebound adjustment system provides 100 different setting variations for the ultimate in handling performance. The Easy Clip System (ECS) spring retainer system allows for rapid spring changes for easy at the track suspension tuning. MDS dampers are ideal for full-race car applications that demand exceptional versatility and fine tuning for track conditions. Bilstein MDS dampers provide proven performance and have taken many race cars to victory at races such as the 24 Hours of Le Mans and the 24 Hours of Nürburgring.

Characteristics include:

Adjustable Damping:Double Adjustable – Compression and Rebound
Body Design:Threaded Body (Coilover)
Body Material:Aluminum
Boot Included:No
Collapsed Length (IN):11.99
Collapsed Length (MM):304.6
Compression @0.52m/s:Adjustable
Extended Length (IN):13.98
Extended Length (MM):355.0
Finish:Clear Anodized
Front Main Spring Rate (lbs/in):798
Front Main Spring Type:Linear
Front Tender Spring Rate (lbs/in):228
Internal Design:Monotube
Lower Mount Type:15mm Heim
PartType:Shocks / Struts
Piston Diameter:46mm
Piston Type:Linear
Position:Front
Prop 65 (Y/N):Y
Prop 65 - Short Label:WARNING: Cancer &amp
Reproductive Harm - www.P65Warnings.ca.gov
Rear Main Spring Rate (lbs/in):798
Rear Main Spring Type:Linear
Rear Tender Spring Rate (lbs/in):228
Rebound @0.52m/s:Adjustable
Segment:Motorsports
Series:MDS
Shaft Diameter:14mm
Spring Hardware:N/A
Spring Seat Included:Yes
Stroke/Travel Length (IN):1.98
Stroke/Travel Length (mm):50.3
Title:Bilstein Shock Absorbers
Upper Mount Type:15mm Heim
Valving Identifier:N/A

Customer Video Reviews

Watch genuine customer videos showing their upgrades and honest results of similar products

Fitment Table

This product is compatible with these vehicles:

Year	Make	Model	Notes	Position
2013	Chevrolet	Corvette	427 Racing Only; Includes racing springs spring hardware and upper mount adapter; Adjustable electronic/magnetic systems must be disabled (parts not included)	Front
2013	Chevrolet	Corvette	Base Racing Only; Includes racing springs spring hardware and upper mount adapter; Adjustable electronic/magnetic systems must be disabled (parts not included)	Front
2013	Chevrolet	Corvette	Grand Sport Racing Only; Includes racing springs spring hardware and upper mount adapter; Adjustable electronic/magnetic systems must be disabled (parts not included)	Front
2013	Chevrolet	Corvette	Z06 Racing Only; Includes racing springs spring hardware and upper mount adapter; Adjustable electronic/magnetic systems must be disabled (parts not included)	Front
2013	Chevrolet	Corvette	ZR1 Racing Only; Includes racing springs spring hardware and upper mount adapter; Adjustable electronic/magnetic systems must be disabled (parts not included)	Front
2012	Chevrolet	Corvette	Base Racing Only; Adjustable electronic/magnetic systems must be disabled (parts not included); Includes racing springs spring hardware and upper mount adapter	Front
2012	Chevrolet	Corvette	Grand Sport Racing Only; Includes racing springs spring hardware and upper mount adapter; Adjustable electronic/magnetic systems must be disabled (parts not included)	Front
2012	Chevrolet	Corvette	Z06 Racing Only; Includes racing springs spring hardware and upper mount adapter; Adjustable electronic/magnetic systems must be disabled (parts not included)	Front
2012	Chevrolet	Corvette	ZR1 Racing Only; Includes racing springs spring hardware and upper mount adapter; Adjustable electronic/magnetic systems must be disabled (parts not included)	Front
2011	Chevrolet	Corvette	Base Racing Only; Includes racing springs spring hardware and upper mount adapter; Adjustable electronic/magnetic systems must be disabled (parts not included)	Front
2011	Chevrolet	Corvette	Grand Sport Racing Only; Includes racing springs spring hardware and upper mount adapter; Adjustable electronic/magnetic systems must be disabled (parts not included)	Front
2011	Chevrolet	Corvette	Z06 Carbon Racing Only; Includes racing springs spring hardware and upper mount adapter; Adjustable electronic/magnetic systems must be disabled (parts not included)	Front
2011	Chevrolet	Corvette	Z06 Racing Only; Includes racing springs spring hardware and upper mount adapter; Adjustable electronic/magnetic systems must be disabled (parts not included)	Front
2011	Chevrolet	Corvette	ZR1 Racing Only; Includes racing springs spring hardware and upper mount adapter; Adjustable electronic/magnetic systems must be disabled (parts not included)	Front
2010	Chevrolet	Corvette	Base Racing Only; Includes racing springs spring hardware and upper mount adapter; Adjustable electronic/magnetic systems must be disabled (parts not included)	Front
2010	Chevrolet	Corvette	Grand Sport Racing Only; Adjustable electronic/magnetic systems must be disabled (parts not included); Includes racing springs spring hardware and upper mount adapter	Front
2010	Chevrolet	Corvette	Z06 Racing Only; Includes racing springs spring hardware and upper mount adapter; Adjustable electronic/magnetic systems must be disabled (parts not included)	Front
2010	Chevrolet	Corvette	ZR1 Racing Only; Includes racing springs spring hardware and upper mount adapter; Adjustable electronic/magnetic systems must be disabled (parts not included)	Front
2009	Chevrolet	Corvette	Base Racing Only; Includes racing springs spring hardware and upper mount adapter; Adjustable electronic/magnetic systems must be disabled (parts not included)	Front
2009	Chevrolet	Corvette	Z06 Racing Only; Includes racing springs spring hardware and upper mount adapter; Adjustable electronic/magnetic systems must be disabled (parts not included)	Front
2009	Chevrolet	Corvette	ZR1 Racing Only; Includes racing springs spring hardware and upper mount adapter; Adjustable electronic/magnetic systems must be disabled (parts not included)	Front
2008	Chevrolet	Corvette	427 Limited Edition Z06 Racing Only; Includes racing springs spring hardware and upper mount adapter; Adjustable electronic/magnetic systems must be disabled (parts not included)	Front
2008	Chevrolet	Corvette	Base Racing Only; Includes racing springs spring hardware and upper mount adapter; Adjustable electronic/magnetic systems must be disabled (parts not included)	Front
2008	Chevrolet	Corvette	Z06 Racing Only; Includes racing springs spring hardware and upper mount adapter; Adjustable electronic/magnetic systems must be disabled (parts not included)	Front
2007	Chevrolet	Corvette	Base Racing Only; Includes racing springs spring hardware and upper mount adapter; Adjustable electronic/magnetic systems must be disabled (parts not included)	Front
2007	Chevrolet	Corvette	Z06 Adjustable electronic/magnetic systems must be disabled (parts not included); Includes racing springs spring hardware and upper mount adapter; Racing Only	Front
2006	Chevrolet	Corvette	Base Racing Only; Includes racing springs spring hardware and upper mount adapter; Adjustable electronic/magnetic systems must be disabled (parts not included)	Front
2006	Chevrolet	Corvette	Z06 Racing Only; Includes racing springs spring hardware and upper mount adapter; Adjustable electronic/magnetic systems must be disabled (parts not included)	Front
2005	Chevrolet	Corvette	Base Racing Only; Includes racing springs spring hardware and upper mount adapter; Adjustable electronic/magnetic systems must be disabled (parts not included)	Front
2004	Chevrolet	Corvette	Base Racing Only; Includes racing springs spring hardware and upper mount adapter; Adjustable electronic/magnetic systems must be disabled (parts not included)	Front
2004	Chevrolet	Corvette	Z06 Racing Only; Includes racing springs spring hardware and upper mount adapter; Adjustable electronic/magnetic systems must be disabled (parts not included)	Front
2003	Chevrolet	Corvette	50th Anniversary Edition Pace Car Racing Only; Includes racing springs spring hardware and upper mount adapter; Adjustable electronic/magnetic systems must be disabled (parts not included)	Front
2003	Chevrolet	Corvette	50th Anniversary Edition Racing Only; Includes racing springs spring hardware and upper mount adapter; Adjustable electronic/magnetic systems must be disabled (parts not included)	Front
2003	Chevrolet	Corvette	Base Racing Only; Includes racing springs spring hardware and upper mount adapter; Adjustable electronic/magnetic systems must be disabled (parts not included)	Front
2003	Chevrolet	Corvette	Z06 Adjustable electronic/magnetic systems must be disabled (parts not included); Includes racing springs spring hardware and upper mount adapter; Racing Only	Front
2002	Chevrolet	Corvette	Base Racing Only; Includes racing springs spring hardware and upper mount adapter; Adjustable electronic/magnetic systems must be disabled (parts not included)	Front
2002	Chevrolet	Corvette	Z06 Racing Only; Includes racing springs spring hardware and upper mount adapter; Adjustable electronic/magnetic systems must be disabled (parts not included)	Front
2001	Chevrolet	Corvette	Base Racing Only; Includes racing springs spring hardware and upper mount adapter; Adjustable electronic/magnetic systems must be disabled (parts not included)	Front
2001	Chevrolet	Corvette	Z06 Racing Only; Includes racing springs spring hardware and upper mount adapter; Adjustable electronic/magnetic systems must be disabled (parts not included)	Front
2000	Chevrolet	Corvette	Base Racing Only; Adjustable electronic/magnetic systems must be disabled (parts not included); Includes racing springs spring hardware and upper mount adapter	Front
1999	Chevrolet	Corvette	Base Racing Only; Includes racing springs spring hardware and upper mount adapter; Adjustable electronic/magnetic systems must be disabled (parts not included)	Front
1998	Chevrolet	Corvette	Base Racing Only; Includes racing springs spring hardware and upper mount adapter; Adjustable electronic/magnetic systems must be disabled (parts not included)	Front
1998	Chevrolet	Corvette	Indianapolis 500 Pace Car Racing Only; Includes racing springs spring hardware and upper mount adapter; Adjustable electronic/magnetic systems must be disabled (parts not included)	Front
1997	Chevrolet	Corvette	Base Racing Only; Includes racing springs spring hardware and upper mount adapter; Adjustable electronic/magnetic systems must be disabled (parts not included)	Front
