NGK Iridium IX Spark Plug - BCPR5EIX
NGK Iridium IX Spark Plug - BCPR5EIX
NGK Iridium IX Spark Plug - BCPR5EIX
NGK Iridium IX Spark Plug - BCPR5EIX
NGK Iridium IX Spark Plug - BCPR5EIX
NGK Iridium IX Spark Plug - BCPR5EIX

NGK Iridium IX Spark Plug - BCPR5EIX

SKU: NGK-BCPR5EIX

Enter your VIN, then Add to cart. We’ll manually check fitment before shipping.

Product details
  • Part Name Spark Plug
  • Brand NGK
  • Country of Manufacture Japan
  • Part Number BCPR5EIX
  • UPC 00087295156889

Specifications

Specifications
Center Electrode Core Material Copper
Center Electrode Design Fine Wire
Center Electrode Tip Material Iridium
Electrical Terminal Type Non-Removable Nut
Grade Type Performance
Ground Configuration J-Gap
Ground Electrode Core Material Nickel
Ground Electrode Quantity 1
Ground Electrode Tip Design Taper Cut
Ground Electrode Tip Material Nickel
Insulator Material Ceramic
Manufacturer Heat Range 5
Metallurgy Single Iridium
Resistance 5000 ohm
Resistor Type Yes
Seat Type Flat
Short Style Spark Plug No
Skirt No
Thread Type Standard Metric
Washer Type Crush
Washers Included Yes
Country of Origin Japan
Estimate Delivery Date
Have Questions?
Ask our experts via Live Chat at the bottom right corner of this page.
100% Fitment Guarantee Warranty Why NGK? Characteristics Interchange/OEM Parts
Fitment is guaranteed:

If your vehicle is listed on the fitment table below, the product will fit your car - we guarantee it. All you need to do is to ensure that the vehicle's Year, Make, Model, Trim, and any other notes specified inside the fitment table are respected.

Customer Video Reviews

Watch genuine customer videos showing their upgrades and honest results of similar products

Fitment Table

This product is compatible with these vehicles:

Year Make Model Notes Position
1994 Saab 900
  • 2.1L
  • Inline engine
  • 4 cylinders
  • 3.66" bore
  • 3.07" stroke
  • Gap 0.028"
1993 Saab 900
  • 2.1L
  • Inline engine
  • 4 cylinders
  • 3.66" bore
  • 3.07" stroke
  • Gap 0.028"
1993 Toyota Celica
  • 1.6L
  • Inline engine
  • 4 cylinders
  • 3.18" bore
  • 3.03" stroke
  • Gap 0.032"
1992 Saab 900
  • 2.1L
  • Inline engine
  • 4 cylinders
  • 3.66" bore
  • 3.07" stroke
  • Gap 0.028"
1992 Toyota Celica
  • 1.6L
  • Inline engine
  • 4 cylinders
  • 3.18" bore
  • 3.03" stroke
  • Gap 0.032"
1992 Toyota Corolla
  • 1.6L
  • Inline engine
  • 4 cylinders
  • 3.18" bore
  • 3.03" stroke
  • Engine code 4A-FE
  • Gap 0.032"
1991 Saab 900
  • 2.1L
  • Inline engine
  • 4 cylinders
  • 3.66" bore
  • 3.07" stroke
  • Gap 0.028"
1991 Toyota Celica
  • 1.6L
  • Inline engine
  • 4 cylinders
  • 3.18" bore
  • 3.03" stroke
  • Gap 0.032"
1991 Toyota Corolla
  • 1.6L
  • Inline engine
  • 4 cylinders
  • 3.18" bore
  • 3.03" stroke
  • Engine code 4A-FE
  • Gap 0.032"
1990 Toyota Celica
  • 1.6L
  • Inline engine
  • 4 cylinders
  • 3.18" bore
  • 3.03" stroke
  • Gap 0.032"
1990 Toyota Corolla
  • 1.6L
  • Inline engine
  • 4 cylinders
  • 3.18" bore
  • 3.03" stroke
  • Engine code 4A-FE
  • Gap 0.032"
1989 Toyota Celica
  • 2.0L
  • Inline engine
  • 4 cylinders
  • 3.39" bore
  • 3.39" stroke
  • Engine code 3S-GTE
  • Gap 0.032"
1989 Toyota Corolla
  • 1.6L
  • Inline engine
  • 4 cylinders
  • 3.18" bore
  • 3.03" stroke
  • Engine code 4A-FE
  • Gap 0.032"
1989 Toyota Corolla
  • Wagon
  • 1.6L
  • Inline engine
  • 4 cylinders
  • 3.18" bore
  • 3.03" stroke
  • Engine code 4AF
  • Gap 0.032"
1988 Toyota 4Runner
  • 3.0L
  • V engine
  • 6 cylinders
  • 3.45" bore
  • 3.23" stroke
  • Gap 0.032"
1988 Toyota Celica
  • 2.0L
  • Inline engine
  • 4 cylinders
  • 3.39" bore
  • 3.39" stroke
  • Engine code 3S-GTE
  • Gap 0.032"
1988 Toyota Corolla
  • 1.6L
  • Inline engine
  • 4 cylinders
  • 3.18" bore
  • 3.03" stroke
  • Engine code 4A-FE
  • Gap 0.032"
1988 Toyota Corolla
  • Wagon
  • 1.6L
  • Inline engine
  • 4 cylinders
  • 3.18" bore
  • 3.03" stroke
  • Engine code 4AF
  • Gap 0.032"
